Pipe markers: Arbeitsluft | German | Luft
Image 1 / 10
€13,14
(€15,90 Incl. tax)
- Article code N017753
Prefer a quote first? Click on "request quote" in your shopping cart
-
Description
- European standard pipe markers for Arbeitsluft.
- Category: Luft
- Text in German.
- With the symbols: -
- Signal word: -
- Available in multiple sizes, see chart
- Markers are printed with a contrasting border in the same colour as the text for improved visibility.
- Perforated arrowhead on both sides: to indicate the flow direction of the substance simply remove
one of the arrowheads (1). - For Dangerous Substances the Chemical symbols conform to European regulations 1272/2008, 790/2009 and 286/2011 (2).
- Colours in accordance with (local) legislation (3).
- Substance name: wide range of legends available, to comply with the country regulations (4).
- Signal word depending on the substance, in accordance with CLP regulations (5).
- High-quality materials: self-adhesive laminated polyester with low chlorine content that is resistant to chemical, ultraviolet rays and extreme weather conditions (6).
Type Lenght Height Character (h) Amount Pipe diameter on liner / linerless On card 150 mm 12 mm 8,00 mm 5 <20 mm on liner On card 250 mm 26 mm 13,30 mm 4 20 mm - 49 mm on liner On card 355 mm 37 mm 16,50 mm 3 50 mm - 99 mm on liner On card 450 mm 52 mm 22,50 mm 2 100> mm on liner On roll 100 mm 60 mm 8,00 mm 505 <70 mm on liner On roll 127 mm 60 mm 8,30 mm 505 <70 mm on liner On roll 100 mm 150 mm 13,00 mm 220 70> mm on liner On roll 127 mm 150 mm 13,30 mm 220 70> mm on liner On roll 250 mm 26 mm 13,30 mm 30 20 mm - 49 mm linerless On roll 355 mm 37 mm 16,50 mm 30 50 mm - 99 mm linerless On roll 450 mm 52 mm 22,50 mm 30 100> mm linerless On roll 100 mm 60 mm 8,00 mm 505 <70 mm linerless On roll 127 mm 60 mm 8,30 mm 505 <70 mm linerless On roll 100 mm 150 mm 13,00 mm 220 70> mm linerless On roll 127 mm 150 mm 13,30 mm 220 70> mm linerless -
Specifications
Substance: Arbeitsluft Danger symbols: In accordance with the CLP regulation Color: Black text on a grey background Material: Self-adhesive laminated polyester Temperature range: -40°C to +120 °C Weatherproof: yes UV-resitant: Yes Chemical resitant: Yes Language: German -
